Product details of the fish dryer machine


Quick Overview

BEAR fish dryer machine is made of materials that are all meet the food grade standard. The raw materials sourced are BPA-free and will not release harmful substances under high temperature. The product brings optimized dehydrating effect. The hot wind of the circulation is able to penetrate into each side of each piece of the food, without affecting its original luster and flavors. The food can be preserved for a long time. This has been proved by our customers who use this product for over 2 years.


Product Description

Next, will show you the details of fish dryer machine.

Main application

Bag drying and sterilizing machine is mainly used for drying and sterilizing all kinds of herbs, spices, teas, and other agricultural products as well as most of the foods.

Working principle

It adopts the microwave as a kind of energy. When the microwave interaction with the material molecular, it occurs molecular polarization, orientation, friction, collision. Then the materials absorb microwave energy and produce heating. It is the material itself absorbing microwave heating from internal to external, at the same time bacterias and worms are killed by the microwave. Different materials have different microwave absorbing capacity, so the heating effects are also not identical, this mainly depends on the dielectric loss of material.

Bag dryer

Product display

Noodle bag dryer
Noodle bag dryer
Herb dryer sterilizer
Herb dryer sterilizer
Beef slices bag dryer sterilizer
Beef slices bag dryer sterilizer
Bag sterilizer
Bag sterilizer
Beef bag dryer
Beef bag dryer
Milk dryer sterilizer
Milk dryer sterilizer

Bag dryer sterilizer

Related parameters

Model

WBSJ-12

WBSJ-36

WBSJ-70

WBSJ-180

Microwave power

12kw

36kw

70kw

180kw

Microwave chamber qty.

2

6

14

26

Machine dimension

7.02*0.72*1.8m

11.7*1.02*2m

22.23*1.02*2m

35.1*1.8*2.4m

Power supply

3Phases 5wires 380v 50hz(or as required)

Microwave frequency

2450±50MHz

Environment temp.

-10~50℃

Relative humidity

≤80%

Microwave leakage

Lower than the national standard <5mw/cm2)

Feed and discharge port height

80mm(or as required)

Conveyor speed

0.25-5m/min, adjustable

Conveyor material

PTFE,PVC,TEFLON,ETC,.

Machine material

SUS304

Standards

In line with the national standard GB10436-89 Comply with national standard gb5226 electrical safety standard

6 (27)

Main features

1. High drying efficiency, easy temperature control, quick bactericidal and insecticide effect, stable working.

2. The microwave heating system adopts the stainless steel drawing board. The stainless steel plate is reliable and corrosion resistant, so that the rigidity of the machine structure is high.

3. The overall structure of the machine is smooth, beautiful, practical,and no exposed rivets, screws and other fasteners. Plates contact place is a certain "R" round corner. The machine is in accordance with GMP requirements.

4. The aircraft microwave generator is the core of the device, in order to achieve its high performance, high reliability, long life, we adopt international first-class electronics, can continuously work 24 hours a day.

5. The strong microwave electromagnetic field is fed by multi - sided broadband, and the network analysis and design are precisly accurate, making the material directly expose to the electromagnetic field energy, which is much greater effect and lower consumption than the side microwave fed. Compared with the normal microwave sterilizer and dryer, our sterilzier’s heating efficiency over 50% greater, and the uniformity of its insecticidal, sterilization, and heating are 2-3 times higher.
