Dry Fruit Packing Machine
Product details of the dry fruit packing machine
Product Introduction
The production of BEAR dry fruit packing machine is strictly carried out according to food industry requirements. Every part is rigorously disinfected before it is assembled to the main structure. The drying temperature of this product is free to adjust. Unlike the traditional dehydrating methods that are unable to change the temperature freely, it is equipped with a thermostat to achieve optimized drying effect. Food dehydrated by this product can be stored for a much longer time compared to the fresh ones which tend to rot within several days. People are free to enjoy healthy dehydrated food at any time.
Main application
Food: Amino acid, vitamin, egg powder, bone powder, protein, milk powder, blood powder, soy sauce powder, coffee, tea powder, glucose, pentadiene carboxylic acid, pectin, flavours, vegetable juice, yeast, starch, etc.
Ceramic: Alumina, zirconia, magnesium oxide, Titania, pottery clay, china clay, all kinds of magnetic porcelain and metal-oxides, etc.
Chemical: Aluminum polychloride, disperse dyes, reactive dyes, organic catalyzer, white carbon black, washing powder, zinc sulfate, silica, sodium metasilicate, potassium fluoride, calcium carbonate, potassium sulfate, inorganic catalyzer, wasted liquid, etc.
Resin Powder
Related parameters
|
Model |
LPG-5 |
LPG-25 |
LPG-50 |
LPG-100 |
LPG-150 |
LPG-200-2000 |
|
Inlet temperature (℃ ) |
140-350(automatically controlled) |
|||||
|
Outlet temperature (℃ ) |
~80-90 |
|||||
|
Max water evaporation capacity (kg/h) |
5 |
25 |
50 |
100 |
150 |
200-2000 |
|
Centrifugal spraying nozzle transmission method |
compressed air transmission |
mechanical transmission |
||||
|
Rotation speed (r.p.m) |
35000 |
20500 |
17600 |
17600 |
15500 |
11570 |
|
Spraying disc diameter (mm) |
50 |
108 |
120 |
130 |
150 |
180-340 |
|
Heat supply |
Electricity |
electricity, steam |
electricity, steam, fuel oil and gas |
Settled by users themselves |
||
|
Max electric heating power(kW) |
9 |
36 |
63 |
81 |
99 |
/ |
|
Dimensions(m) |
1.8*0.93*2.2 |
3*2.7*4.26 |
3.7*3.2*5.1 |
4.6*4.2*6 |
5.5*4.5*7 |
depends on the concrete conditions |
|
Dried powder collecting |
≥95% |
|||||
Mian Features
1.Fast drying speed; LPG high speed centrifugal spray dryer greatly increasing the surface area of the material after the liquid is atomized; it can instantly evaporate 95% -98% of water in the stream of hot air; it takes only a few seconds to complete drying, which is especially suitable for drying heat sensitive materials.2. Our products have a good uniformity, mobility and solubility, high purity and good quality.3. Simplified production process, easy to operate and control. Liquid of 40-60% moisture content (up to 90% for special materials) can be dried into powder products at a time, without crushing and screening after drying, which reduces production process and improve product purity. The size, bulk density, moisture can be adjusted within a certain range by changing operation conditions. It is convenient to do control and management.
Hot Tags: Resin powder spray dryer, Coffee powder spray dryer, LPG Spray dryer, Catalyst spray dryer, Sodium fluoride spray dryer, Protein powder spray dryer, Formaldehyde silicic acid spray dryer,China, Manufacturers, Suppliers, Factory, Customized
